Модель: TP46MEC
| Профиль | D | d* | Z | I | Макс.об/мин | Код | SAP |
Цена, евро |
|---|---|---|---|---|---|---|---|---|
| 1 | 170 | 30 (35) | 4 | 8 | 7 500 | TP46MEC001 | F03FC20518 | 778.0 |
| 2 | 170 | 30 (35) | 4 | 8 | 7 500 | TP46MEC002 | F03FC20519 | 778.0 |
| 3 | 170 | 35 (50) | 4 | 8 | 7 500 | TP46MEC003 | F03FC20520 | 778.0 |
| 4 | 170 | 30 (35) | 4 | 8 | 7 500 | TP46MEC004 | F03FC20521 | 778.0 |
| 5 | 170 | 30 (35) | 4 | 8 | 7 500 | TP46MEC005 | F03FC20522 | 778.0 |
| 6 | 170 | 35 (50) | 4 | 8 | 7 500 | TP46MEC006 | F03FC20523 | 778.0 |
| 7 | 170 | 30 (35) | 4 | 8 | 7 500 | TP46MEC007 | F03FC20524 | 778.0 |
| 8 | 170 | 30 (35) | 4 | 8 | 7 500 | TP46MEC008 | F03FC20525 | 778.0 |
| 1 | 170 | 32 | 4 | 8 | 7 500 | TP46MEC321 | F03FC24466 | 778.0 |
| 2 | 170 | 32 | 4 | 8 | 7 500 | TP46MEC322 | F03FC24467 | 778.0 |
| 3 | 170 | 32 | 4 | 8 | 7 500 | TP46MEC323 | F03FC24468 | 778.0 |
| 4 | 170 | 32 | 4 | 8 | 7 500 | TP46MEC324 | F03FC24469 | 778.0 |
| 5 | 170 | 32 | 4 | 8 | 7 500 | TP46MEC325 | F03FC24470 | 778.0 |
| 6 | 170 | 32 | 4 | 8 | 7 500 | TP46MEC326 | F03FC24471 | 778.0 |
| 7 | 170 | 32 | 4 | 8 | 7 500 | TP46MEC327 | F03FC24472 | 778.0 |
| 8 | 170 | 32 | 4 | 8 | 7 500 | TP46MEC328 | F03FC24473 |
778.0 |
| Запасные части | Размеры мм | Код | SAP |
Цена, евро |
|---|---|---|---|---|
| Проставка | 50 x 2 x 30 | AN01MA0209 | F03FC00035 | 5.0 |
| Проставка | 52 x 2 x 32 | AN01MX0209 | F03FC24489 | 5.0 |
| Ключ-шестигранник | 4 x 110 | CB03M BA9 | F03FA00163 | 4.5 |
| Ключ-шестигранник | 5 x 110 | CB03M EA9 | F03FA00169 |
2.5 |
| Ключ Torx | T20 | CB03M CC9 | F03FA00167 | 1.0 |
| Клин | 28 x 34,5 x 8 | CN46M 001 | F03FC01438 | 15.0 |
| Зубцовый нож | 34 x 3,5 x 16 | SR06MDBA302 | F03FC24197 | 21.0 |
| Сектор | 25 x 45 x 6 Z1 | SR11MSBE301 | F03FC24212 | 9.0 |
| Винт | M5 x 8 | VT05M AA9 | F03FA04444 | 1.5 |
| Винт | M6 x 13 | VT16M AE9 | F03FC20658 | 1.5 |
| Установочная плита | 22 x 1,7 x 6,5 | VT18M GA9 | F03FA04488 | 2.5 |
| Винт | M10 x 16 | 2616M EE9 | F03FA07426 | 1.0 |
| Клин | 28 x 34,5 x 8 | CN46M 002 | F03FC01439 | 15.5 |
| Зубцовый нож | 34 x 3,5 x 16 | SR06MSBA302 | F03FC24200 | 21.0 |
| Сектор | 25 x 45 x 6 Z1 | SR11MDBE301 | F03FC24207 | 9.0 |
| Винт | M5 x 8 | VT05M AA9 | F03FA04444 | 1.5 |
| Винт | M6 x 11,5 | VT16M AB9 | F03FA04477 | 1.5 |
| Установочная плита | 22 x 1,7 x 6,5 | VT18M GA9 | F03FA04488 | 2.5 |
| Винт | M10 x 16 | 2616M EE9 | F03FA07426 | 11.5 |
